Welding Neck Flanges

Odelya® Welding Neck Flanges have a long tapered hub or neck, which is gradually connect the flange with the pipeline or fitting, providing the same wall thickness in the butt welding area. Moreover, due to smooth transition of wall thickness from the neck base to the pipe or fitting, the weld neck flanges are provided with important reinforcement, matching bore of the mating line pipe as well.

Odelya® Welding Neck (WN) Flanges are used in high stress applications involving sub-zero or elevated temperatures and high pressure, as the neck or hub provides stress distribution of the piping system and excellent strong connection. Additionally, design of Odelya® WN Flanges provides reduction of corrosion, turbulence at joints and welding area can be easily examinated by radiography.

Production Standards: ANSI B 16.5, MSS SP 44; pressure classes: 150LB (PN20), 300LB (PN50), 400LB(PN68), 600LB (PN100), 900LB, 1500LB, 2500LB. ISO 7005-1, DIN 2631 PN6, DIN 2632 PN10, DIN 2633 PN16, DIN 2634 PN25, DIN 2635 PN40, DIN 2636 PN64, DIN 2637 PN100, DIN 2638 PN160.

Dimensions: ½" - 24", 22" – 48"
